GON SERIES COMPRESSED AIR FILTERS
August 24, 2021 |
By Kaito-Admin
0
Odor Removal Filter AMF
FEATURE ODOR REMOVAL FILTER "AMF"
・Efficiently removes odors in compressed air with an activated carbon element
This unit is designed for removing odors from places, such as clean rooms,
which must remain odorless
・Activated carbon element with large filtration area
・Easy element replacement and installation
Micro Mist Separator AMD
FEATURE MICRO MIST SEPARATOR "AMD"
・Can separate and remove aerosol state oil mist and remove carbon or
dust of 0.01 μm or larger
・Should be used as a pre-filter for compressed air for precision instruments
or clean rooms requiring high levels of clean air
Mist Separator AM
FEATURE MIST SEPARATOR "AM"
・Can separate and remove oil mist and remove solid particles,
such as rust or carbon, of 0.3 μm or larger
Main Line Filter AFF
FEATURE MAIN LINE FILTER "AFF"
・Can remove impurities, such as oil, water, and foreign matter, in compressed air,
improve the function of a downstream dryer, extend the life of precision filters,
and prevent problems with the equipment
Main Line Filter AFF NEW SERIES
FEATURE MAIN LINE FILTER NEW "AFF"
・Increase in an air flow capacity due to lower pressure drop contributing to energy saving
- Flow capacity: 14.5 m3/min (ANR)
- Increased by up to 20% compared with the current model
- Pressure drop: 5 kPa or less
・Lightweight: Max. 52% lighter (10.5kg→5.0kg)
Light body weight to thinner stainless steel bowl.
・Space-saving design, Labor-saving in piping!
Water droplets and solid particles can be removed with just one AFF.
A separate filter for removing water droplets (water separator, AMG
series) is not necessary any more. Space and piping work are reduced.
・Easier replacement of the element
Stopper function prevents the bowl from falling
Water Separator AMG
FEATURE WATER SEPARATOR
・Compressed air without water can be obtained.
・Water drop removal ratio: 99%
